20MP UHD Imaging
Industrial camera with fast autofocus captures pores, fine lines and pigment in ultra‑clear detail.
10‑Spectrum Modes
RGB / UV / UV‑Wood / PL (parallel & cross) / Red / Brown / Thermal / Melasma / UV‑Damage.
15.6″ HD Display
Large, bright screen for chair‑side consultation and elegant client presentations.
Shadowless Lighting
18 high‑CRI LEDs with compact light‑blocking hood ensure uniform, reproducible imaging.
Local + Cloud
Use offline anywhere or sync to cloud for multi‑store management and QR code report sharing.
64GB + SD Expansion
Ample storage with SD backup for easy data transfer and long‑term client archives.
Comprehensive Analysis — 18 + 5 + 1 Dimensions
The M17 quantifies five categories across full‑face and spot modes (up to 50× magnification).
Cleansing
Pores, Porphyrins, Comedo, Sebum, Clogged Pore.
Pigmentation
Epidermis Pigment, Dermis Pigment, Brown Area, UV Damage, Melasma.
Sensitivity
Sensitive Area, Spider Vein, Thermal map.
Acne & Anti‑Aging
Acne, Wrinkle, Texture, Moisture, Collagen + Future Aging Simulation.
10‑Spectrum Imaging — Surface to Deep
RGB White Light▾
Highlights pores, wrinkles and acne not obvious to the naked eye.
UV & UV‑Wood▾
Reveals underlying acne, pigments and fluorescence reactions (Wood’s lamp 320–400 nm).
PL (Parallel & Cross)▾
Parallel PL emphasizes surface texture; Cross PL suppresses glare to show deeper vessels and pigments.
Red / Brown / Melasma▾
Isolates hemoglobin and melanin to map sensitivity, basal pigmentation and melasma distribution.
Thermal & UV‑Damage▾
Heat maps reflect sensitivity severity; UV‑damage highlights areas of inadequate sun protection.
Technical Specifications
| Product Name | Intelligent Facial Skin Analyzer |
|---|---|
| Model | M17 |
| Power | 25W |
| Rated Power Supply | 110–230 VAC / 50–60 Hz |
| Resolution | 20 Megapixels |
| Spectrum Modes | 10 |
| Operating System | Android 12 |
| Shooting Mode | Automatic |
| Built‑in Display | 15.6″ HD |
| RAM | 2GB |
| Storage | 64GB (SD card expansion supported) |
| Device Size | 60.6 × 45.5 × 22.1 cm |
| Package Size | 70 × 55 × 29.5 cm |
| Weight | Net 5 kg; Gross 9 kg |
Includes 18× shadowless light, light‑blocking hood, one‑touch power/lock, handheld magnifier support, and dual local/cloud analysis.
FAQ
Does it support report sharing?
Yes. Generate on‑screen QR codes so clients can view reports on their phones instantly.
Can I manage multiple stores?
Cloud console lets you update products and campaigns across locations with one click.
